CotoMOS® C241S High Current MOSFET Relay

The C241S series of high-current MOSFET relays feature high current switching capability to 5A with a low ON resistance of 0.02Ω Nominal and are capable of providing 1,500V of input to output isolation.

Designed for Automatic Test Equipment (ATE), Industrial Controls, Measurement & Instrumentation applications, the CotoMOS® C241S Series relay is capable of handling 20V load conditions. For different requirements, please contact your Coto Applications Engineer for assistance.

NEW! C241S High-Current MOSFET Series Features

  • Contact Form: 1A
  • Load Voltage: 20V
  • Load Current: 5A
  • Low On-Resistance: 0.02Ω Nominal
  • Output Capacitance: 150pF Typical
  • Low Off-State Leakage Current: 1.0μA Maximum
  • Input/Output Isolation: 1500Vrms
  • Arc-Free with no Snubbing Circuits
  • High-Reliability Solid State Design
  • RoHS Compliant

Applications

  • Automatic Test Equipment (ATE)
  • Industrial Controls
  • Instrumentation
  • Measurement Equipment
CotoMOS C217S

NEW! C241S High-Current MOSFET SERIES DIMENSION

In Inches (Millimeters)
  • CotoMOS C241S Dimensions
CotoMOS C241S Table

NEW! C241S High-Current MOSFET SERIES TECHNICAL INFORMATION
